Applications:
Pharmaceutical and Biotechnology: Used in high-purity fluid transfer systems for its clean surface and resistance to contamination.
Chemical Processing: Suitable for handling aggressive chemicals and gases in high-precision piping systems.
Semiconductor Manufacturing: Ensures high-purity gas and fluid transfer in critical production processes.
Automotive and Aerospace: Used in fuel lines, hydraulic systems, and exhaust components requiring high strength and durability.
ASTM A269 seamless tubes are crafted from high-performance stainless steel grades such as 304, 304L, 316, 316L，2205 and 2507. These materials are selected for their exceptional corrosion resistance, mechanical strength, and ability to perform in extreme environments. The bright annealing process is applied to create a clean, polished surface that is highly resistant to oxidation and suitable for demanding applications requiring high-purity standards.
Designed for critical applications, ASTM A269 bright annealed seamless tubes deliver superior strength, dimensional accuracy, and a smooth surface finish. Their seamless construction eliminates weak points, ensuring reliability under high pressure and precision systems. The bright annealing process not only improves surface aesthetics but also enhances the tube’s resistance to contamination, making it suitable for applications where cleanliness and durability are essential.
Process of Precision tubes: Bright annealed & Polished Grit K240/320
Size Range ： O.D. Range: 3.18mm-38mm; W.T. Range: 0.5-5mm, length: up to 30meters
Grades that we can offer:Austentic stainless (304/304L/304H,316/316L/316Ti, 321/321H,317L/310S/347H...
Duplex steel (S31803/2205,s32750/2507, s32760)
Nickel alloy( Alloy 20, Inconel 601/600/625, Hastalloy C22/C276, 718...
Copper:(C11000,C12000,C10100...)
|
TABLE Permissible Variations in Dimensions AS ASTM A269 |
||||||
|
Group |
Size,Outside |
Permissible |
Permissible |
Permissible Variations in Cut Length,in.[mm] |
Thin Walled Tubes |
|
|
Over |
Under |
|||||
|
1 |
Up to 1/2[13] |
±0.005 [0.13] |
±15 |
1/8[3.2] |
0 |
... |
|
2 |
1/2 to 1 1/2 |
±0.005 [0.13] |
±10 |
1/8[3.2] |
0 |
less than 0.065 in.[1.65 mm]nominal |
|
[13 to 38],excl |
||||||
|
3 |
1 1/2 to 3 1/2 |
±0.010 [0.25] |
±10 |
3/16[4.8] |
0 |
less than 0.095 in.[2.41 mm]nominal |
|
[38 to 89],excl |
||||||
|
4 |
3 1/2 to 5 1/2 |
±0.015 [0.38] |
±10 |
3/16[4.8] |
0 |
less than 0.150 in.[3.81 mm]nominal |
|
[89 to 140],exc |
||||||
|
5 |
5 1/2 to 8 |
±0.030 [0.76] |
±10 |
3/16[4.8] |
0 |
less than 0.150 in.[3.81 mm]nominal |
|
[140 to 203],excl |
||||||
|
6 |
8 to 12 |
±0.040 [1.01] |
±10 |
3/16[4.8] |
0 |
less than 0.200 in.[5.08 mm]nominal |
|
[203 to 305],excl |
||||||
|
7 |
12 to 14 |
±0.050 [1.26] |
±10 |
3/16[4.8] |
0 |
less than 0.220 in.[5.59 mm]nominal |
|
[305 to 356],excl |
||||||
Shanghai Toko Technology Co.,ltd. is professional ASTM A269 bright annealed seamless tubes precision tubes 304L/ 316L/ 2205/ 2507 Suppliers and ASTM A269 bright annealed seamless tubes precision tubes 304L/ 316L/ 2205/ 2507 Factory, located in Shanghai, China, and has been worked in the field of industrial piping for 11 years. We are committed to manufacturing and exporting stainless steel seamless pipe, stainless steel welded pipes, stainless steel fittings and flanges, nickel alloy products, Titanium seamless and welded tubes, etc. Our factories are all ISO&PED certificated, and the products can be produced in standard ASTM, JIS, DIN, EN, GOST, etc. Our products are widely used in the Oil and Gas, Petrochemical, Sugar Refining, Water Process, Desalination, Geothermal industry etc. We exported to dozens of countries and regions such as USA, Canada, Japan, Germany, France, Korea, Turkey ect.
